Technical specifications

400 Hz series resonant technology
3kW, 60 kV - 60 mA switch selectable operation

Tube shield: Vertical, 4 exits, one line-focus assembly, three blanking discs
Loading: 3.0 kW maximum
Voltage range: 10-60 kV
Current range: 10-60 mA
Voltage/current steps: 5 kV, 5 mA
Voltage/current stability: 0.005% per 10% mains variation
Power consumption: < 4 kW
Water supply: 3.5 l/min, minimum
Operational temperature range: 5-40 °C
Operational humidity range: (Colling water below dew point) 0-80%
Temperature drift: < 100 ppm / °C after 1 hour
Ripple: 40 V eff/mA
