The XR-100CR is a high performance x-ray detector, preamplifier, and cooler system using a thermoelectrically cooled Si-PIN photodiode as an x-ray detector. Also mounted on the 2-stage cooler are the input FET and a novel feedback circuit. These components are kept at approximately -55 °C, and are monitored by an internal temperature sensor. The hermetic TO-8 package of the detector has a vacuum tight thin Beryllium window to enable soft x-ray detection.

Features

    Si-PIN Photodiode
    2-Stage Thermoelectric Cooler
    Temperature Monitor
    Beryllium Window
    Multilayer Collimator
    Hermetic Package (TO-8)
    Wide Detection Range
    Easy to Operate


Applications

    X-Ray Fluorescence
    RoHS/WEEE
    Portable Instruments
    OEM
    Nuclear Medicine
    Teaching and Research
    Art and Archaeology
    Process Control
    Mössbauer Spectrometers
    Space and Astronomy
    Environmental Monitoring
    Nuclear Plant Monitoring
    Toxic Dump Site Monitoring
    PIXE
